Pass Band Freq. (MHz) |
1880~1900 |
|
Insertion Loss (dB) |
0.8 |
|
Ripple£¨dB£© |
0.2 |
|
VSWR |
1.3 |
|
Attenuation (dB) |
30dB @806~1850MHz |
|
40dB@ 1920MHz~2010 | |
|
60dB@ 2010MHz~2025MHz | |
|
60dB @2110~2170 | |
|
Intermodulation (dBc) |
150(43dBm input power) |
|
Delay (ns) |
200 |
|
Power Handling (W) |
50 |
|
Operation Temp (¡æ) |
-25~+75 |
|
Operation Humidity |
95£¥ |
|
Connector Type |
SMA(F)
Male and Female |
|
Impedance (¦¸) |
50 |
