UPLINK |
DOWNLINK |
|
Pass Band Freq. (MHz) |
1882.50 ~ 1890.00 |
1962.50 ~ 1970.00 |
|
Insertion Loss (dB) |
1.0 |
1.0 |
|
VSWR |
1.25 |
1.25 |
|
Attenuation (dB) |
£¾ 45 @1000~1880.05MHz
£¾ 45 @1920MHz~1960.05MHz |
£¾ 45 @1920~1960.05MHz |
|
Power Handling (W) |
£¾ 100 |
£¾ 100 |
|
Connector Type |
7/16 (F) | |
|
Operation Temp (¡æ) |
-25~+75 | |
|
Operation Humidity |
95£¥ | |
|
Dimension (mm) |
231 x 121 x 88 | |
|
Impedance (¦¸) |
50 | |
