Item |
SPEC |
|
Center Frequency Fo (MHz) |
978 |
|
Notch BW (@3dB) (MHz) |
35 |
|
Attenuation at Notch BW (dB) |
30 |
|
Passband (MHz) |
F0+/-120MHz |
|
Insertion Loss at Passband (dB) |
3.0 |
|
Power Handling (W) |
50dBm |
|
Connector Type |
SMA |
|
Operation Temp (¡æ) |
-25~+75 |
|
Operation Humidity |
95£¥ |
|
Impedance (¦¸) |
50 |
