QDC
Applications
• Commercial
Features
• Coaxial Resonator Designs
• Low Insertion Loss
• High Reject
• High Power
Specifications
|
Channels |
CH2 |
CH3 |
CH4 |
CH5 |
CH1 |
|
Frequency（MHz） |
700~760 |
870~880 |
930~954 |
954~960 |
2130~2145 |
|
Insertion Loss（dB） |
≤0.6 |
≤1.0 |
≤4.5 |
≤4.5 |
≤0.6 |
|
Rejection (dB) |
≥80 |
≥80 |
≥70 |
≥70 |
≥70 |
|
Ripple （dB） |
≤0.4 |
≤0.5 |
≤0.5 |
≤0.5 |
≤0.4 |
|
VSWR |
≤1.4 | ||||
|
Impedance (Ω) |
50 | ||||
|
Connecter Type |
N-F | ||||
|
Power Handling (w) |
100W | ||||
|
Operation Temp. (℃) |
| ||||
