QFC1-21-5725-5875-00
Satellite Communication Filter
Applications
• Satellite Communication
Features
• Coaxial Resonator Designs
• Low Insertion Loss
• High Reject
|
Frequency Bandwidth |
5725~5875MHz |
|
Insertion Loss |
0.6dB |
|
Rejection |
40dB@6420MHz 40dB@5180MHz |
|
Return Loss |
18dB |
|
Connectors |
SMA(F) |
|
Power |
1W |
|
Impedance (Ω) |
50 Ohm |
|
Operating Temp. |
-30~70℃ |
