QFC1-21-2399-2424-00
Satellite Communication Filter
Features
• Coaxial Resonator Designs
• Low Insertion Loss
• High Reject
Specification
|
Product Name |
Bandpass Filter |
|
Frequency Range |
|
|
Center frequency |
2412MHz |
|
3dB Bandwith |
25MHz |
|
Insertion loss |
¡Ü2.0dB |
|
Return Loss |
¡Ý18dB |
|
Pass Band Ripple |
0.5dB |
|
Band rejection |
¡Ý40dB@fc+/-27MHz |
|
Impedance |
50 Ohm |
|
Power Handing |
>50W |
